Manual of Engineering Drawing : Technical Product Specification and Documentation to British and International Standards

Helps practicing and student engineers to produce engineering drawings and annotated 3D models that comply with the advanced BSI and ISO standards of technical product specifications and documentation. This title encompasses topics such as orthographic and pictorial projections, dimensional, geometrical and surface tolerancing, and more.

Manual of Engineering Drawing is a comprehensive guide for experts and novices for producing engineering drawings and annotated 3D models that meet the recent BSI and ISO standards of technical product documentation and specifications. This fourth edition of the text has been updated in line with recent standard revisions and amendments. The book has been prepared for international use, and includes a comprehensive discussion of the fundamental differences between the ISO and ASME standards, as well as recent updates regarding legal components, such as copyright, patents, and other legal considerations. The text is applicable to CAD and manual drawing, and it covers the recent developments in 3D annotation and surface texture specifications. Its scope also covers the concepts of pictorial and orthographic projections, geometrical, dimensional and surface tolerancing, and the principle of duality. The text also presents numerous examples of hydraulic and electrical diagrams, applications, bearings, adhesives, and welding. The book can be considered an authoritative design reference for beginners and students in technical product specification courses, engineering, and product designing.
