Protection Principle and Technology of the VSC-Based DC Grid

This book discusses key techniques of protection and fault ride-through in VSC-HVDC grids, including high-speed selective protection, DC fault current limitation, converter restarting, and DCCB reclosing strategies.

This book discusses key techniques of protection and fault ride-through in VSC-HVDC grids, including high-speed selective protection, DC fault current limitation, converter restarting, and DCCB reclosing strategies. It investigates how high-speed transient-variable-based protection can be used to improve grids’ acting sensitivity, acting reliability, and ability to withstand high transition resistance compared with traditional protection. In addition, it discusses the applicability of the pilot protections, including the current differential protection and travelign-wave based protection, in the dc grid, as well as the improved methods. Furthermore, it proposes several DC FCL topologies, which are suitable for DC grids. Lastly, in the context of overhead line application conditions, it explores converter restarting and DCCB reclosing strategies, which not only identify the fault property, but also limit the secondary damage to the system, improving the system’s operation security and reliability. As such, the book offers a comprehensive overview of original and advanced methods and techniques for the protection of VSC-HVDC grids.
